Graxx GTS Flatbar

Graxx GTS Flatbar

All-terrain gravel bike


Graxx GTS Flatbar: The all-terrain carbon gravel bike

The Graxx GTS Flatbar: accessible versatility for all your adventures. It excels on both roads and trails. Its high-modulus carbon frame combines performance and lightness, while its upright position and comfort-optimized geometry invite you to cover long distances effortlessly. Although its comfort slightly lags behind the GTO version, this can be improved by opting for wider tyres.

Designed for regular athletes and explorers alike, it offers ample carrying options to keep you well-equipped for every journey. With its dynamic handling, it remains enjoyable and efficient, even on extended rides.

Select your model

Graxx GTS Flatbar M1
Graxx GTS Flatbar M1
Frame
Origine
Graxx GTS Flatbar
Derailleurs
Shimano
Tiagra Fitness disc
Crankset
Shimano
Tiagra Compact 50/34 BS
Cassette
Shimano
HG-50 11-34
Wheelset
Mavic
Allroad
Seat post
Uno
Monobloc 27,2 350mm
Handlebar
Ritchey
Flat 580 mm
Stem
Ritchey
Switch Comp (semi-intégrée)
Prix : 1 954 € Poids : 8 930 g
Graxx GTS Flatbar M2
Graxx GTS Flatbar M2
Frame
Origine
Graxx GTS Flatbar
Derailleurs
Shimano
GRX 400 2x10s Flatbar
Crankset
Shimano
GRX 600 46/30 10s
Cassette
Shimano
HG-50 11-34
Wheelset
Mavic
Allroad
Seat post
Uno
Monobloc 27,2 350mm
Handlebar
Ritchey
Flat 580 mm
Stem
Ritchey
Switch Comp (semi-intégrée)
Prix : 2 022 € Poids : 9 101 g
Graxx GTS Flatbar M3
Graxx GTS Flatbar M3
Frame
Origine
Graxx GTS Flatbar
Derailleurs
Shimano
SLX 1x12v
Crankset
Shimano
GRX 820 40D
Cassette
Shimano
SLX M7100 12s 10-51
Wheelset
Mavic
Allroad
Seat post
Uno
Monobloc 27,2 350mm
Handlebar
Ritchey
Flat 580 mm
Stem
Ritchey
Switch Comp (semi-intégrée)
Prix : 2 250 € Poids : 8 904 g
Graxx GTS Flatbar M4 AXS
Graxx GTS Flatbar M4 AXS
Frame
Origine
Graxx GTS Flatbar
Derailleurs
Sram
Apex XPLR AXS 1x12v
Crankset
Sram
Apex 12v 40D
Cassette
Sram
Apex 12v AXS XPLR 11-44
Wheelset
Mavic
Allroad
Seat post
Uno
Monobloc 27,2 350mm
Handlebar
Ritchey
Flat 580 mm
Stem
Ritchey
Switch Comp (semi-intégrée)
Prix : 2 718 € Poids : 8 836 g
Graxx GTS Flatbar M5 AXS
Graxx GTS Flatbar M5 AXS
Frame
Origine
Graxx GTS Flatbar
Derailleurs
Sram
Apex XPLR AXS 1x12v
Crankset
Sram
Apex 12v 40D
Cassette
Sram
Apex 12v AXS XPLR 11-44
Wheelset
Prymahl
Vega A30 R
Seat post
Ritchey
1B WCS 27.2
Handlebar
Ritchey
MTN Rizer WCS 580
Stem
Ritchey
Switch Comp (semi-intégrée)
Prix : 3 111 € Poids : 8 132 g

Technological benefits

Graxx GTS

Graxx GTS

Le Graxx GTS est la nouvelle génération du Graxx que vous connaissez et qui s'est imposé comme une référence dans le secteur du gravel. Il conserve ses qualités dynamique et sa capacité de rouler au long court. Bien qu'il n'égale pas le confort du Graxx GTO, il rend cependant le carbone haut module au plus grand nombre
SPS carbon moulding

SPS carbon moulding

La technologie SPS est un procédé innovant utilise des contremoules internes positionnés sur toute la longueur des trois tubes principaux du triangle avant, compactant la fibre de carbone de manière uniforme pour optimiser rigidité et durabilité.

Contrairement au moulage EPS utilisé sur les gammes supérieures, la technologie SPS simplifie les processus de fabrication tout en maintenant un excellent niveau de performance. Ce savoir-faire permet de concevoir des cadres performants, dynamique et offrant une précision de pilotage remarquables.

Avec SPS, la gamme GTS prouve qu’il est possible d’allier technologie avancée et accessibilité, en faisant de chaque coup de pédale une expérience fluide et agréable.
CCT+® technology

CCT+® technology

The CCT+® (Continuous Carbon Tubing®) rear triangle further enhances these features. The chain stays and seat stays on the Graxx are connected by a single continuous carbon tube, with no hard points between the bottom bracket shell and the seat clamp. Vibration from an imperfect ride surface is spread over the entire length of this continuous tube (bases + stays) for better filtration.
Internal cable routing

Internal cable routing

Other than the visual aspect, integration offers a number of significant advantages, especially for bikepackers.
The cables and outers do not restrict steering. It took months to develop this method of integration on our Fraxion, and so why not on our new GRAXX.
It’s because of this method of integration that the steering is even more fluid than non-integration.
Compatible with both 650B and 700C wheelsets

Compatible with both 650B and 700C wheelsets

Compatible with either 650B or 700C wheelsets, the Graxx is designed to take tyres up to 47mm.

The frame allows for maximum 700x45 and 650x47 tyre sizes for more versatility. You can give your bike as many personalities as you like, whether it's that unbeatable trail racer or the sharp blade for smooth asphalt, you choose the specifications and ride the bike that reflects your personality.
Technical specs

Technical specs

Graxx GTS frame
Bottom bracket: BSA 68mm
Top headset bearing: IS52 / 28.6
Lower headset bearing: IS52 / 40
Seatpost: 27.2mm
Maximum tyre dimensions: 700x45
or, 650x47
Front & rear flat mount brake discs 180mm or 160mm
Thru-axles: front 12 x 100 & rear 12 x 142mm
Integrated seat post clamp
Chainrings max: Single 38 to 44T or Double 46/30 to 52/36T
Water bottle cages: 3
Internal routing
Standard fork eyelets 64mm for water bottle cages
Tubus Tara luggage rack eyelets
